| 型號 (Model) |
TR-DCV1A4-200MV |
TR-DCV1A4-2V |
TR-DCV1A4-20V |
TR-DCV1A4-200V |
| 測量範圍 (Measure Range) |
0 - 200 mV DC |
0 - 2 DCV |
0 - 20 DCV |
0 - 200 DCV |
| 輸出 (Output) 4 - 20 mA |
0 mV DC =4 mA
100 mV DC=12 mA
200 mV DC=20 mA
|
0 DCV =4 mA
1 DCV =12 mA
2 DCV =20 mA
|
0 DCV =4 mA
10 DCV =12 mA
20 DCV =20 mA
|
0 DCV =4 mA
100 DCV =12 mA
200 DCV =20 mA
|
| 外部調整 (External Adjustment) |
ZERO VR , SPAN VR |
| 電源供應 (Power Supply) |
90 - 260 ACV/ 50 Hz/60 Hz |
| 操作溫度 (Operation Temperature) |
0 - 50 ℃ ( 32 - 122 ℉) |
| 操作溼度 (Operation Humidity) |
Less than 80 %RH |
| 選購品 (Optional) |
Current shunt
ST 50A/50mV
ST 100A/50mV
ST 1000A/50mV
|
None |
|
放置 (Mounting)
|
Din rail or Wall |
| 箱體 (Case) |
ABS plastic |
| 其他 (Others) |
Two wires input |
