| 型號 (Model) |
TR-DCA1A4-200UA |
TR-DCA1A4-2MA |
TR-DCA1A4-20MA |
TR-DCA1A4-200MA |
TR-DCA1A4-2A |
TR-DCA1A4-5A |
| 測量範圍 (Measure Range) |
0 - 200 uA DC |
0 - 2 mA DC |
0 - 20 mA DC |
0 -200 mA DC |
0 - 2 A DC |
0 - 5 A DC |
| 輸出 (Output) 4 - 20 mA |
0 uA DC =4 mA
100 uA DC =12 mA
200 uA DC =20 mA
|
0 mA DC =4 mA
1 mA DC =12 mA
2 mA DC =20 mA
|
0 mA DC =4 mA
10 mA DC =12 mA
20 mA DC =20 mA
|
0 mA DC =4 mA
100 mA DC=12 mA
200 mA DC=20 mA
|
0 A DC =4 mA
1 A DC =12 mA
2 A DC =20 mA
|
0 A DC =4 mA
2.5 A DC =12 mA
5 A DC =20 mA
|
| 外部調整 (External Adjustment) |
94 dB Cal. VR |
ZERO VR , SPAN VR |
| 電源供應 (Power Supply) |
90 - 260 ACV/ 50 Hz/60 Hz |
| 操作溫度 (Operation Temperature) |
0 - 50 ℃ ( 32 - 122 ℉) |
| 操作溼度 (Operation Humidity) |
Less than 80 %RH |
| 放置 (Mounting) |
Din rail or Wall |
| 箱體 (Case) |
ABS plastic |
| 其他 (Others) |
Two wires input , 500 mA fuse |
Two wires input , 2 Amp fuse |
Two wires input , 6 Amp fuse |
