PM-9107 壓力/差壓計 HOME » 上偉科技企業有限公司 » 電子型錄


1.
照片-1


上一個商品 下一個商品




PM-9107 壓力/差壓計



PM-9107 壓力/差壓計



特色

  • 測量範圍 :

             PM-9107 : 0 ~ 7000 毫巴(mbar)

  • 雙壓力感應器,可測量壓力及差壓

  • 精確度 : ±2%

  • 八種單位選擇切換 : mbar ' psi ' Kg/cm2 ' mm/Hg ' inch/Hg ' meter/H2o ' inch/H2O ' Atmosphere

  • 讀值鎖定及記錄測量中之最大/最小值

  • RS-232 / USB 連接介面(軟體選購)

  • Size : 180 x 72 x 32mm

FEATURES

Dual & differential input, 7000 mbar ( 7 bar ) maximum range.(PM-9107)

Aplication : Industrial, laboratory, heating, ventilation, medical hospital, used for air or not corrosive and not ionized gas.

Sensor is built inside the housing.

Single lugs for pipe connection.

8 kind display units ( mbar, psi, Kg/cm^2 mm Hg, inch Hg, meter H20, inch H20, Atmosphere ) select by push button on the front panel.

Records max. & min. readings.

Zero button on the front panel, easy to offset the zero value.

Data Hold.

RS232 PC serial interface, can match the personal computer used as the Data Logger, Recorder.... and other modern pressure measuring system.

規格

電路 (Circuit)

Microprocessor LSI circuit.

顯示 (Display)

61 mm x 34 mm supper large LCD display. 15 mm ( 0.6" ) digit size.

顯示單位 (Display units)

mbar, psi, Kg/cm^2, mm/Hg, inch/Hg, meter/H2O, inch/H2O, Atmosphere.

功能 (Function)

Dual & differential input, data hold, zero/relative, memory.

歸零調整 (Zero adjust)

Push button on the front panel.

差距調整 (Span adjust)

Push button gain adjustment, usage for calibration precisely if necessary.

感應器 (Sensor)

* Sensor is built inside the housing.
* Piezoelectric sensor.
* Used for dry, non-corrosive and non-ionic air and gas only.
* Liquid is prohibited.

資料鎖定 (Data hold)

By push button.

資料鎖定 (Data hold)

By push button.

資料記憶 (Data record)

Record maximum & minimum readings.

資料輸出 (Data output)

RS 232 PC serial interface.

取樣時間 (Sampling Time)

Approx. 0.8 sec

關機 (Power off)

Auto shut off, saves battery life, or manual off by push button.

操作溫度 (Operating Temp. )

0 to 50 ℃.  (32 to 122 ℉ ).

操作溼度 (Operating Humidity)

Less than 80% R.H.

電源供應 (Power Supply)

006P DC 9V battery(heavy duty).

電源電流 (Power current)

 Approx. DC 8.5 mA

體積 (Dimension)

180 x 72 x 32 mm ( 7.1 x 2.8 x 1.3 inch )

重量 (Weight)

345 g/0.76 LB

附件 (Standard Accessory)

* Sensor probe...................... 1 PC.
* Instruction manual............. 1 PC.
* Hard carrying case.............. 1 PC.

選購附件 (Optional Accessories)

* Software for data logging & data recorder, Model : SW-U801-WIN
* RS232 cable, UPCB-01
* USB cable, USB-01

電器規格 ELECTRICAL SPECIFICATIONS (23±5 ℃)

Unit   Max. range Resolution Accuracy
m bar 7000 m bar 5 m bar ± 2 % F. S. ( F.S. : full scale )

Note :

Included linearity, hysteresis and repeatability

psi 101.5 psi 0.5 psi
Kg/cm^2 7.135 Kg/cm^2 0.005 Kg/cm^2
mm/Hg 5250 mm/Hg 5 mm/Hg
inch/Hg 206.7 inch/Hg 0.1 inch/Hg
meter/H2O 71.35 meter/H2O 0.05 meter/H2O
inch/H2O 2810 inch/H2O 2 inch/H2O
Atmosphere 6.905 Atmosphere 0.005 Atmosphere
